(EV-M2M-007) 72V 12KW Tile Rear Hub Motor
Email : info@etechpro.com
Whatsapp : +86-13373669025
Contact Us
Chat Now

Product Description

Main parameters

Product modelEV-M2M-007
Motor sizeφ287*237 mm
Motor weight20 KG
Installation position

Rear

Rated voltage72 V
Rated power3 KW
Peak power12 KW
Rated torque22 N.m
Peak torque259 N.m
Rated speed1300 RPM
Peak speed1300 RPM
Appearance colorMatte Black
Maximum efficiency≥86 %
Transmission ratio1:1
Number of pole pairs16
Position sensorHall 120°
Temperature sensorNTC: KTY83-122
Insulation classB（130℃)
Protection gradeIP67
Transmission formDirect Drive
Cooling methodNatural air cooling

Dimension



Wiring Diagram



InstructionThree Phase Line
ColorYellowGreenBlue
DefinitionUVW
Connection MethodGrounding Lug: 16-6
Signal Line
ColorRedBlackYellowGreenBlueWhitePhase Wire Gauge
DefinitionVINGNDHaHbHcNTC16mm²x1.25m（Twisted pair signal line shielding）
Connection MethodPlastic Case: DJ7061F-1.8-21-2
